Armourdeck Steel Formwork (Bondeck)

ArmourDeck 600 – General Product Data

Gauge BMT (mm) Lineal Metres per Tonne Mass Linear Mass (kg/m2) Zinc Coating (g/m2) Yield Strength(MPa) Coverage (m2/tonne)
0.75 161.4 6.20 10.33 Z350 550 96.84
1.00 122.8 8.14 13.57 Z350 550 73.68



ArmourDeck 600 – General Product Data

Gauge BMT (mm) Lineal Metres per Tonne Mass Linear Mass (kg/m2) Zinc Coating (g/m2) Yield Strength(MPa) Coverage (m2/tonne)
0.75 334 2.99 9.98 Z350 550 100.2
1.00 254 3.93 13.12 Z350 550 76.2



Description

Manufactured by Big River Group and supplied by Meshcrete as an authorised reseller, Armourdeck steel formwork provides a fast and efficient method for creating suspended concrete slabs. Ideal for both concrete and steel frame construction, this product offers excellent spanning capabilities, high composite strength, and minimal deflection. The composite action of the steel decking enhances efficiency by forming a high-performance composite slab.

Armourdeck steel formwork is roll-formed from hot-dip zinc-coated, high-tensile steel strip, available in a range of base metal thicknesses (BMT) conforming to AS 1397. This ensures durability and robust performance in various construction environments. The superior design and material quality of Armourdeck make it a reliable choice for builders and engineers looking to optimise their construction processes and achieve superior structural results.
